16-062 MadJax 4" King XD Lift Kit for Yamaha Drive2 with Independent Rear Suspension
16-062 MadJax 4" King XD Lift Kit for Yamaha Drive2 with Independent Rear Suspension
16-062 MadJax 4" King XD Lift Kit for Yamaha Drive2 with Independent Rear Suspension
16-062 MadJax 4" King XD Lift Kit for Yamaha Drive2 with Independent Rear Suspension
16-062 MadJax 4" King XD Lift Kit for Yamaha Drive2 with Independent Rear Suspension
16-062 MadJax 4" King XD Lift Kit for Yamaha Drive2 with Independent Rear Suspension
16-062 MadJax 4" King XD Lift Kit for Yamaha Drive2 with Independent Rear Suspension

MJ 4″ KING BOLT LIFT YAM DRIVE2 INDEPENDENT REAR SUSPENSION

SKU: 16-062 Categories: , Tags: , , , , , , , , , , , , , ,

Original price was: $1,358.95.Current price is: $870.95.

The King XD lift kit series is the latest offering from MadJax, providing a reliable and comfortable ride to the driver. This lift kit was designed with the installer in mind, reducing install times by up to 25%. Adjusting the camber/toe during the installation has never been easier, utilizing our turnbuckle and jam nut design. The Kingpin design replaces traditional hiem joints, providing a more simple and durable lift kit.

Features & Specifications:

  • Fits Yamaha Drive2 (2017-Up) Golf Carts with independent rear suspension
  • Provides a 4" Lift with clearance for up to 22" tires
  • Faster installation times compared to other lift kit styles
  • Turnbuckle style camber adjustment for more efficient tire setting (no need to remove tires for adjustment after installation!)
  • Reliable kingpin design
  • Pre-assembled and pre-greased lower main frame
  • Durable urethane bushings
  • Armor coating provides your new lift kit protection from the elements
  • Bolt-on design - No Drilling required!
  • Includes thread-locking adhesive

Tech Tips:

  • Minimum Wheel Size: 10"
  • Recommended Minimum Tire Size: 20" Outer Diameter
  • Recommended Maximum Tire Size: 22" Outer Diameter
  • Front Counterweight Kit is recommended with this lift kit to help increase front steering stability
  • Installation videos are available to assist during installation (QR codes linking to the installation video can be found on the installation instructions included with this lift kit)
